360°攝影機
磐石智慧科技 360°全景攝影機（RockCore 360° Cam）採用高解析度感光元件與專利拼接技術，能以單機實現 360° 無死角監控，減少多攝影機部署成本。
產品支援 PoE 供電與低光補償模式，適用於全天候監控環境。
攝影機可與磐石 AI Box、Rec Box 與 Central Management System 完整串接，支援電子圍籬警報、事件錄影回放與設備狀態監控。
本系列提供多種解析度與外觀選項，能靈活應用於智慧工地、工廠監控、停車場、校園及公共安全場域，協助企業以更低成本實現高效、智慧的全景 AI 安防架構。
產品支援 PoE 供電與低光補償模式，適用於全天候監控環境。
攝影機可與磐石 AI Box、Rec Box 與 Central Management System 完整串接，支援電子圍籬警報、事件錄影回放與設備狀態監控。
本系列提供多種解析度與外觀選項，能靈活應用於智慧工地、工廠監控、停車場、校園及公共安全場域，協助企業以更低成本實現高效、智慧的全景 AI 安防架構。
RC-360-2
360 Degree AI Patrolling Monitor
Features
INTERFACE : Ethernet 10/100/1000 via RJ45 x1
Maximum output Resolution : 2880x5760@15fps
OPTICAL FEATURES : 360° (Horizontal) x 85° (Vertical)
field of view F2.5 aperture
Sensor : 1/2.7" 5M CMOS sensor x4
AUDIO : Microphone x1
Maximum output Resolution : 2880x5760@15fps
OPTICAL FEATURES : 360° (Horizontal) x 85° (Vertical)
field of view F2.5 aperture
Sensor : 1/2.7" 5M CMOS sensor x4
AUDIO : Microphone x1
Specifications
| InterfacePowerPower | Ethernet 10/100/1000 via RJ45 x1 |
|---|---|
| Power | PoE 802.3at Class 4 |
| Power | 13W |
| Video Output | 640x320@30fps 1920x960@30fps 1920x1080@30fps 3840x904@30fps 3840x1920@30fps 1360x5760@30fps 2880x5760@15fps H.264 in RTP/RTSP streaming |
| Control | Compatible with ONVIF profile S / OSC API |
| Optical Features | 360° (Horizontal) x 85° (Vertical) field of view F2.5 aperture 1/2.7" 5M CMOS sensor x4 |
| Audio | Microphone x1 |
| Physical Features | 102 x 114 x 62mm ( Not including accessory cap, lens, PoE Cable) Approximately 720g 1/4" camera screw hole and VESA MIS-B 50 x 20mm interface Silver grey anodized aluminum IK08 housing with IP66 sealing MIL-STD-810H testing:Transit drop (48" /1.22m) ・ Vibration ・ Functional Shock ・ Humidity ・ Salt Fog (with rubberized keyboard) ・ Altitude Operation / Air Carriage ・ Solar Radiation ・ Thermal Shock |
| Temperature | -10°C to 50°C operating, -20°C to 60°C storage |
| Electrical Safety | CB: IEC 62368-1: 2018 ED.3 EU / CE: EN 62368-1 ED.2 |
| EMI/EMS Regulation | Taiwan / EMC: BSMI(CNS15936) EU / CE: EN 55032 / EN 55035, Class A USA / FCC: 47 CFR Part15, Subpart B, Class A Canada / ISED: ICES-003, Issue 7, Class AAS/NZS: CISPR 32, Class A |
| Environmental | RoHS - Directive (EU) 2011/65/EU & 2015/863/EU |
| Compliance | NDAA |
